SL3100 Water Soluble Green Fluorescent Tracer Dye
Suitable wavelength: 365NM
Solubility(Petroleum products): Insoluble
Solubility (Water): Fully dissolved
Density（20 °C）: 1.10-1.13
Stickiness（25C，mPa.S）: ≤60
Flash Point: >100°C (212°F)
Share:
What is SL3100 Water Fluorescent Tracer Dye？
SL3100 is a concentrated water-soluble dye containing Fluorescein disodium salt in a compound of water and glycol solvent system.
The product is a green colored liquid and can be mixed with water or antifreeze fluid in various amounts.
SL3100 has excellent fluorescence characteristics and light fastness even if in high pH environment. The product was designed for use in antifreeze, water tracing, and a variety of other chemical applications.
Parameter of SL3100 Water Fluorescent Tracer Dye
| Content | Data |
|---|---|
| Suitable wavelength for fluorescence inspection. | 365NM |
| Typical usage ratio(L) | 1-1.5 : 3000 |
| Solubility(Petroleum products) | Insoluble |
| Solubility (Water) | Fully dissolved |
| Density（20 °C） | 1.05—1.15 |
| Flash Point | >100°C (212°F) |
| Ionic | Anionic |
| Stickiness | ≤60 |
| Seal Material Compatibility | All rubber, plastic and metal parts (including concentrated and diluted dye) |
Operation
Turn the system off and pour in the appropriate Reveal Additive
Run the system to circulate the additive
Shine the UV lamp on the system and spot the fluorescent glow of any leaks – big or small
Make your work easier with easy to see, easy to use Fluorescent Dye Tracing Products from UV Dyes.
Recommended Use Level
The following recommended dosing amounts are starting dosing amounts for typical applications, but the true dosing amount depends on:
UV intensity, fluorescent intensity, background color of the system being spiked, desired fluorescent intensity, and light intensity of the work environment.
Water: 300-500 ppm Antifreeze: 500-1000 ppm
The addition ratio is: 1-1.5/3000. (That is, 1 liter of tracer dye can be mixed with 3000 liters of water; the price of the tracer dye depends largely on the concentration ratio. SL3100 is a super-concentrated tracer.)
Application
Leak detection of roofs/Terraces/Balconies/Floors ects
Leak and infiltration detection of buildings
Water flow testing of wastewater, rainwater and industrial water
Agricultural simulation of diffusion
Search for hydraulic connections between the natural environment and building
Search for leaks in civil engineering: dams, dykes, reservoirs
Search for water infiltration in floors, walls and ceilings
Visual identification and detection of buried pipe connections
Chemical simulation of product dispersion
Leak detection in underfloor heating, glycol cooling circuits
Leak detection in storage tanks
