SL8803 Super UV LED Flashlight
Model: SL8803-S, SL8803-AR
Peak-Wavelength: 365-370NM
Number of UV LEDs: 3 x 5W 365NM UV LED with lens, average LED life is 30,000 hours
UV Intensity: 4,000-16,000 UW/cm2 at 15inch(380mm) -See the list
Low visible light emission: less than 2 foot-candles (22 lux)
Power supply: 100-240 universal chargers AC/50HZ; Polymer battery pack DC.
Irradiated Area in 38cm Distance: 160mm (Diameter)
Stability of UV Intensity: > 90%
Product Size: 73*193 mm
WEIGHT: 400g without accessories
Share:
What Is SL8803 Super UV LED Flashlight？
SL8803 Series adopts advanced LED cold light source technology, utilizing three Nichia 5W 365 nm LEDs (NCSU033B(T)) combined with high-quality optical lenses to deliver strong and stable UV performance.
Its broad-beam design provides an exceptionally wide coverage area, improving inspection efficiency, while the compact lamp head allows easy access to tight or hard-to-reach spaces where larger UV lamps cannot operate effectively.
Parameter of SL8803 Super UV LED Flashlight
| Model | SL8803-S | SL8803-AR |
|---|---|---|
| Number of UV LEDs | 3 x 5W 365NM UV LED, Optical lens + filter | 3 x 5W 365NM LED, Optical lens + filter |
| UV Intensity at 15inch (380mm) | 16000uw/cm2 | 4000uw/cm2 |
| Irradiated Area in 38cm Distance | 130 mm(Diameter) | 160 mm(Diameter) |
| Visible light emission | < 2 FC(20 lux) with black light filter | < 0.5FC(5 lux) with white light filters, meets ASTM E3022 and RRES 90061 |
| Power supply | Polymer battery pack DC | Polymer battery pack DC |
| Application | All Aeronautics NDT | Except Aeronautics NDT |
Video
Features
- 5W 365NM NICHIA True 365nm wavelength UV light.
- Less than 2 FC Candles of white Light.
- Meets ASTM UV-A intensity and wavelength specifications for FPI and MPI.
- Certificate of compliance for both output and wavelength measurements is supplied with each lamp.
- 100% solid state cold ensures working properly in strong magnetic field.
Specifications
- Model: SL8803-S, SL8803-AR
- Peak-Wavelength: 365-370NM
- Number of UV LEDs: 3 x 5W 365NM UV LED with lens, average LED life is 30,000 hours
- UV Intensity: 4,000-16,000 UW/cm2 at 15inch(380mm) -See the list
- Low visible light emission: less than 2 foot-candles (22 lux)
- Power supply: 100-240 universal chargers AC/50HZ; Polymer battery pack DC.
- Irradiated Area in 38cm Distance: 160mm (Diameter)
- Stability of UV Intensity: > 90%
- Product Size: 73*193 mm
- WEIGHT: 400g without accessories
Main Purposes
A: Fluorescence detection
iron and steel, non-ferrous metals, automobiles, aircraft, fluorescent penetrant inspection, fluorescent magnetic particle inspection.
B: Pollution check
electronic components, boards, dust inspection, LCD panel, checked into the clean room.
C: Leak Check
hydraulic machines, sump, pipe and other oil spill inspection, leak detection using fluorescent agents.
D: Degreasing cleaning validation
the food industry, kitchen, cooking utensils, tableware degreasing cleaning
Application
Penetration testing
Fluorescence detection
Biopolymers
在此添加您的标题文本
Fluorescence observation
Refrigerant leak detection
Engine oil leak detection
Criminal Investigation: fingerprints, blood observed
Fluorescence observation of ore
Detection of oil cleaning
Variants
- SL8803 Series: SL8803-S and SL8803-AR
- (because We master the core technology,We can provide different UV Intensity UV light,They can meet different customer and industry)
Attention to:
- SL8803-Aerospace RRES90061 Meets Rolls-Royce RRES 90061 Requirements ASTM E1417,ASTM E1444, ASTM E 709, ASTM E2297, ASTM E3022 compliant
- Meets ASTM UV-A intensity and wavelength specifications for FPI and MPI.
