SL8904-G Green Surface Inspection Lamp
Light Source: 4 pcs 5W 525 NM LED with lens and white side light
Irradiated Area: Ø20cm at 45cm Distance
Stability of Led Lamp: > 90%
Lifespan: Average LED life is 30,000 hours
Power Supply: 100-240 chargers AC/50HZ; Polymer battery pack DC.
Share:
What is SL8904-G Inspection Lamp?
SL8904-G handheld inspection lamp is with 4pcs 525NM green light LEDs, and 6pcs side white light.
Glass surface testing principle: green light are sensitive sources for human eyes, which can effectively inspect the flaws on the surface of the workpiece. According to the requirement from client and demand from the market, we developed the SL8904 series multi-function inspection lamp with our multiple optical lens technology. Its inspection effect reaches the same level to the related top brand items.
Specifications
1. Anodized high strength aluminum alloy, very durable
2. Use 4 pcs 5W 525 NM LED with lens and white side light, average LED life is 30,000 hours
3. Light Intensity:50000 lx at 30cm
4. Irradiated Area in 38cm Distance:150*180mm
5. Power supply: 100-240 universal chargers AC/50HZ; Polymer battery pack DC.
6: Irradiated Area in 45cm Distance:Ø20cm
7: Stability of Led Lamp: > 90%
8: Product Size:150*200*106 mm
9: Weight: 660g without accessories
Application
- TFT-LCD panel
- Color filters, touch panel
- Cell Gap MURA
- Surface flathess
- Optical film materials
