SLF6300 Fluorescence LED Light Source Adapter for Stereo Microscope
Share:
What is SLF6300 Fluorescence LED Light Source Adapter for Stereo Microscope
SLF6300 excitation light source can offer a complete solution for the stereo microscope’s fluorescence observation need. It is with all the necessary accessories. With our SLF6300 excitation light source adapter, without destroying the existing stereo microscope, the protein fluorescence excitation test can be completed. We have developed a series modular excitation light source, up to 8 different solution for your selection. You can have one or several solutions for the protein excitation light source.
Just fix 1 set of SLF 6300 excitation light source adapter on your microscope. It can be used for various fluorescence excitation test such as fruit flies, zebrafish, and salamanders.
Parameter of SLF6300 Fluorescence LED Light Source Adapter for Stereo Microscope
| Model | SLF6300-XX fluorescent excitation light source adapter for stereo microscope | Remark | |||
|---|---|---|---|---|---|
| LED No and specification | 1 pcs 5W LED and optical lens | Customize-design | |||
| LED wavelength | 365NM | 395NM | 455NM | 525NM | |
| Intensity of excitation light source(30CM) | 90000 uw/cm2 | 120000 Uw/cm2 | 20000Lx | 50000lx | |
| Irradiated area （Φ） | Φ5-15cm diameter aperture | ||||
| Dimming | Had rotation dimming and light modulator | ||||
| Power | Light modulator | ||||
| Size and specification | 80 * 40mm | Net weight: 0.1kg without accessory | |||
Slf6300 Excitation Light Source Adapter Accessories
A complete system with an excitation/emission, including: SLF 6300 lamp holder, flexible gooseneck, magnet lamp holder, special dimmer, adapter ring, and observation filter.
- Flexible gooseneck lamp holder and power supply, modular light source, can be combined freely.
- SLF800 adapter ring for microscope, suitable for any stereoscope and filter.
- Light modulator: a customize-design dimmer, can be adjust the brightness of excitation light source, from 0-100%
- Filter: Usually 3 different filter for your selection (SLF400-UV; SL500-blue light; SLF600-green light)
- Observation filter: several different observation filter for your selection, SLFF400-ultraviolet; SLFF500—blue light; SLFF600—green light.
Fluorescence List And Selection Of Various Observation Wavelength
UV:
Excitation wavelength 330nm~400nm emission wavelength: 425nm
Violet:
Excitation wavelength 395nm~415nm emission wavelength: 455nm
Blue:
Excitation wavelength: 420nm~485nm Emission wavelength: 515nm
Green:
Excitation wavelength: 460nm~550nm Emission wavelength: 590nm
| Excitation light source code | Excitation wavelength | Emission wavelength | Observable fluorescence |
|---|---|---|---|
| 365NM-U | 365NM | 425NM | DAPI |
| 395NM-V | 395NM | 455NM | CFP, BFP |
| 455NM-B | 455NM | 510NM | GFP, fluorescein |
| 525-G | 525NM | 595NM | DsRed, TdTomato |
